LD Suite — Levodopa PK Tools

LD Suite

Levodopa Pharmacokinetic Tools

🧮

Rytary Calculator

6-hour lookback window with time-weighted IR dosing. Calculates total effective LD with 200/210mg thresholds.

📈

Daily LD PK Simulator

24-hour plasma concentration curve. Scheduled doses + unlimited rescue doses with custom Rytary/IR mix.

⚖️

Equivalence Plot

Rytary vs Sinemet IR comparison. User-configurable doses with bidirectional equivalence calculation.

🔬

Pulse Model

Three-pulse absorption window visualization. Rytary 580mg tri-phasic kinetics vs Sinemet 2×100mg.

\n\n

Peak LD

—

ng/mL

Min Trough

—

ng/mL

Time <810

—

hrs/day

Time >2800

—

hrs/day

\n\n

24-Hour Levodopa Plasma Concentration

—

Rytary + rescues (total)

Rytary only (no rescues)

Equiv IR overlay

Therapeutic ≥810

High risk ≥2800

Dysk EC50 600

\n\n

\n Scheduled Doses\n ⌄\n

Morning245+145+95 default

\n \n

Noon245+145+95 default

\n \n

Evening245+145+145 default

\n \n

Bedtime245+145+95+95 default

\n \n

\n\n

\n Modifiers\n ⌄\n

Show equivalent IR CD-LD overlayDashed yellow — same LD doses, IR kinetics (sharp peaks, fast drop)

High-fat breakfast with morning doseDelays Tmax +2hr, Cmax −21% (Yao et al. 2016)

High-protein meal near any doseBBB amino acid competition → ~20% CNS reduction

Poor sleep / high stressRaises effective thresholds ~120 ng/mL

PK profile

\n \n

\n\n

\n Rescue / PRN Doses · added to main curve\n ⌄\n

\n \n

\n PK model: Bateman 1-compartment, unit-corrected (mg×1000/L = ng/mL). CL/F=56.8 L/hr, V/F=114.4 L, ke=0.497 hr⁻¹ (FDA NDA 203312). Rytary tri-phasic: ka_IR=3.2, ka_ER1=0.55, ka_ER2=0.18 hr⁻¹ (fractions 27/48/25%). IR CD-LD: ka=3.5 hr⁻¹. PD correction +38% Cmax. Food effect: Yao et al. 2016. EC50: Mao et al. 2013. Semi-quantitative — not a substitute for clinical judgment. Intrasubject variability ±20%.\n

Pulse 1 · IR phase (27%) · 0–2 hr

Pulse 2 · ER phase 1 (48%) · 2–4 hr

Pulse 3 · ER phase 2 (25%) · 4–6+ hr

Sinemet 2×100 mg IR

\n\n

—

\n\n

Rytary 580 mg — Total (fasted)

Rytary 580 mg — Fed (high-fat +2hr delay, −21% Cmax)

Sinemet 2×100 mg IR (fasted)

Therapeutic ≥810 ng/mL (EC50 UPDRS)

Dyskinesia EC50 ≥600 ng/mL

Rytary 580 mg LD · PD Patient PK

Tmax (fasted)~2–2.5 hr

Tmax (high-fat meal)~4.5–5 hr (+2hr delay)

Cmax estimate (fasted)~2,680 ng/mL

Cmax (fed)~2,117 ng/mL (−21%)

Duration >50% Cmax4–5 hr

Absorption phasesIR 27% / ER1 48% / ER2 25%

Relative bioavailability vs IR~70%

Terminal t½1.9 hr

Fluctuation index1.5 (vs 3.2 for IR)

PD vs healthy Cmax+38% / AUC +44%

Intrasubject variability~19% CV (low)

Sinemet 2×100 mg IR · PD Patient PK

Tmax (fasted)~1.0 hr

Cmax (2×100 mg, est.)~2,180–3,010 ng/mL

Duration >50% Cmax~1.5 hr

Dose-norm Cmax10.9 ng/(mL·mg)

Absolute bioavailability~84%

Terminal t½1.6 hr

<10% peak by~5 hr

Fluctuation index3.2

Intrasubject variability~37% CV (higher)

Equivalence basisPeak CNS effect (not duration)

\n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n

Window	Time range	Absorption source	% of total Rytary dose	Approx IR equivalent	Your experiential observation
Pulse 1	0–2 hr	IR beads	~27% → ~157 mg LD active	~1× Sinemet 100 mg (157mg × 31% delivery ≈ 49mg IR-equiv)	Onset comparable to Sinemet — rapid initial effect
Pulse 2	2–4 hr	ER phase 1	~48% → ~279 mg LD active	~1× Sinemet 100 mg sustained (dominant plateau phase)	Sustained therapeutic effect — longest window
Pulse 3	4–6+ hr	ER phase 2	~25% → ~145 mg LD active	~½–1× Sinemet 100 mg waning (late tail, most variable)	Late coverage — most sensitive to food, GI motility, stress
Sinemet 2×100mg	0–2 hr	IR only	100% → 200 mg LD	Reference	Sharp peak, rapid decline — equivalent first 2hr window to Rytary Pulse 1+early 2

\n Model basis: Hsu et al. J Clin Pharmacol 2015 · Yao et al. Clin Neuropharmacol 2016 · Mittur et al. Clin Pharmacokinet 2017 · FDA NDA 203312 (CL/F = 56.8 L/hr, V/F = 114.4 L). PD patient correction +38% Cmax applied. EC50: Mao et al. J Clin Pharmacol 2013 (dyskinesia EC50 600 ng/mL, UPDRS EC50 810 ng/mL).

\n Pulse window model: The 2hr functional windows reflect the experiential pharmacodynamics of sequential bead-cohort gastric emptying pulses, not discrete bead-release events. Published absorption fractions (27/48/25%) are shown as shaded phase contributions to the total curve. The tartaric acid excipient in ER component 2 modulates dissolution by local intestinal pH, creating a progressive release gradient that may manifest as functionally distinct motor windows. Effect-site equilibration t½ ~24–36 min means CNS effect lags plasma by ~30 min, further blurring phase boundaries experientially.

\n Equivalence note: Dr. Yang's equivalence claim (Rytary 580mg ≈ Sinemet 2×100mg) refers to comparable peak motor effect, not total exposure or duration. Rytary sustains therapeutic concentration for ~4–5hr vs ~1.5hr for Sinemet. This is a semi-quantitative decision-support model — not a substitute for formal PK studies or clinical judgment.\n

\n \n Rytary Dose\n Total LD mg (e.g., 245, 485, 580)\n \n

\n \n mg LD\n

\n \n IR CD/LD Dose\n Total LD mg (e.g., 100, 200, 250)\n \n

\n \n mg LD\n

\n \n

Rytary → IR Equivalent

—

Peak motor effect comparable to

IR → Rytary Equivalent

—

Peak motor effect comparable to

—

\n Rytary (single dose, fasted)\n

\n Sinemet IR (single dose, fasted)\n

\n Rytary (fed, high-fat meal)\n

\n Therapeutic window (EC50 UPDRS ~810 ng/mL threshold)\n

\n Dyskinesia risk (EC50 ~600 ng/mL lower bound shown)\n

Rytary 580 mg LD

Tmax (fasted)~2.5 hr

Tmax (fed)~4.5–5 hr

Cmax (fasted, est.)~2680 ng/mL

Duration >50% Cmax~4–5 hr

Absorption phasesIR 27% / ER1 48% / ER2 25%

Relative bioavail.~70% vs IR

t½ (terminal)1.9 hr

Sinemet 200 mg IR

Tmax (fasted)~1.0 hr

Cmax (est.)~2188 ng/mL

Duration >50% Cmax~1.5 hr

Dose-norm Cmax10.9 ng/(mL·mg)

Bioavailability~84% absolute

t½ (terminal)1.6 hr

<10% peak by~5 hr

\n Model basis: Hsu et al. (J Clin Pharmacol 2015), Yao et al. (Clin Neuropharmacol 2016), Mittur et al. (Clin Pharmacokinet 2017), FDA NDA 203312. PK model uses published CL/F = 56.8 L/hr, V/F = 114.4 L, tri-phasic Rytary absorption (Ka1 back-calculated from 27%/48%/25% fraction split and published Tmax/curve shape). IR CD-LD modeled as standard 1-compartment first-order absorption/elimination. PD patient correction factor (+38% Cmax, +44% AUC vs healthy subjects) applied to both curves.

\n Equivalence claim context: Dr. Yang's equivalence of Rytary 580 mg ≈ Sinemet 2×100 mg refers to comparable peak motor effect, not duration or total exposure. The key difference is duration: Sinemet 2×100 mg sustains therapeutic levels for ~1.5 hr; Rytary 580 mg sustains them for ~4–5 hr. This tool scales doses proportionally based on the 580:200 reference ratio (2.9:1). This is a semi-quantitative decision-support model — not a substitute for clinical judgment.\n

Daily LD PK Simulator

Rytary 580 mg · Three-Pulse Window Modelvs Sinemet 2×100 mg IR

Rytary 580 mg LD · PD Patient PK

Sinemet 2×100 mg IR · PD Patient PK

Rytary vs Sinemet IR

Rytary 580 mg LD

Sinemet 200 mg IR

Rytary 580 mg · Three-Pulse Window Model
vs Sinemet 2×100 mg IR
